- more flow
- less size
- quicker response
- faster dynamics
- smaller hysteresis
- higher reliability
- better repeataability
- remarkable cleanliness
- ensured delivery
- fair pricing
HVT products are typically used in the fields of
Industrial and mobile hydraulics
Pumps, motors, control systems, valve blocks
Mechanical engineering
Prime movers, stationary and mobile machines
Automotive industry
Drive trains, suspension, brakes and steering, hydraulic and pneumatic comfort systems
Pressure Relief Valve
The control valve is a preassembled spring-loaded valve designed to limit/hold the pressure in hydraulic systems. The valve is supplied ready for insertion (cartridge) without any mounting and/or sealing elements.
| Size | AD < 15 mm |
| Opening pressure | between 10 bar and 900 bar |
| Flow | 0,1 l/min up to 25 l/min @ 10 bar delta |
| Internal leakage | usually < 1 ml/min |
Non-Return Valve
The Non-Return-Valve ist a preassembled springloaded valve to prevent backflow or returning pressure-peaks in hydraulic systems.
| Size | AD < 10 mm |
| Opening Pressure | between 0,07 bar and 15 bar |
| Flow | up to 4 l/min @ 1 bar delta |
| Internal leakage | usually < 1 ml/min |
